A DC-DC converter converts one DC voltage to another. The operating voltage of different electronic devices can vary over a wide range, making it necessary to provide a voltage for each device. All models with adjustable output can also be used as a battery charger for example to charge a 12 Volt starter or accessory battery in an otherwise 24V system. All models with adjustable output can be paralleled to increase output current
Up to five units can be connected in parallel.

Specifications

SKU E.CON-VONI70
Barcode # 8719076023043
Brand Victron
Shipping Weight 1.0000kg
Shipping Width 0.115m
Shipping Height 0.085m
Shipping Length 0.225m
Shipping Cubic 0.002199375m3
  • Input voltage range (V): 18-35
  • Under voltage shutdown (V): 14
  • Under voltage restart (V): 18
  • Output voltage adjustable with potentiometer: yes
  • Output voltage (V): Adjustable 10–15V F set 13,2V
  • Efficiency (%): 92
  • Suitable to buffer-charge a battery: yes
  • Can be connected in parallel: yes
  • Continuous output current (A): 70
  • Max. Output current (A): 85
  • Fan assisted cooling (temp. controlled): yes
  • Galvanic isolation: no
  • Off load current: < 20mA
  • Remote on-off: yes
  • Operating temperature range (derate 3% per °C above 40°C): -20 to +55°C
  • DC connection: Faston tabs 6.3 mm
