ALLSPARK FUSE BLOCKS PROVIDE THE ULTIMATE PROTECTION FOR YOUR OFFROAD POWER SYSTEM



Eliminate messy, unsafe wiring with this compact design, allowing you to consolidate all low current circuits into one central location.



Our AllSpark Fuse Blocks come in either a 6 Way or 12 Way. They have a max current of 100A (30A max per circuit 12-32V DC) and are equipped with LED indication lights to clearly show blown fuse locations.



WHATS IN THE BOX

  • 1 x AllSpark Surface Mount Fuse block with indication light - 12 Way
  • Fuses and labels

12 MONTHS MANUFACTURERS WARRANTY
30 DAY MONEY BACK GUARANTEE

  • 100A max current - 30A max per circuit 12-32V DC
  • Positive and negative bus
  • Output ring terminals
  • LED indication light - to show blown fuse locations

PRODUCT SPECIFICATIONS - ALLSPARK FUSE BLOCKS

MODEL 6 Way Flush 12 Way Flush 6 Way Surface 12 Way Surface
Electrical
Main Line Terminal M5 Threaded Studs
Rating 100A 32V DC Max
Wire Size (AWG) 4-6 4
Individual Circuits Terminal Copper/nickel plating 1/4" (6.3mm) - blade M4 Screws - ring terminals
Rating 30A 32V DC Max
Wire Size (AWG) 8-16
Material
Base PA66
Cap PC
Terminal Nickel Plated Copper
Screw Stainless Steel
Gasket Butadiene rubber N/A
Seal Ring Silicone N/A
Label PP x 70
Dimension (W x L mm) 55 X 60 (cut out) 55 x 97.5 (cut out) 84 x 94 85 x 137
Fuse Size 1A to 30A

Specifications

SKU AS-FUSEBLOCK12SURF
Brand AllSpark
Shipping Weight 0.3070kg
Shipping Width 0.180m
Shipping Height 0.050m
Shipping Length 0.150m
Shipping Cubic 0.001350000m3
