MEET THE ALLSPARK ULTIMATE POWER PACK, YOUR GO-TO PORTABLE POWER SOLUTION FOR ALL YOUR TOURING ADVENTURES



Boasting a whopping 100Ah of battery capcacity with a high current rate to power the AllSpark 2000W inverter, you can kiss power woes goodbye. Paired with the in-built RedArc 1225 Core DCDC and Victron bluetooth battery monitor, experience reliable, rapid charging, and rest easy knowing your devices are always fueled for action.



The AllSpark Ultimate Power Pack: Because when you're on the go, power should never be an afterthought.



Includes:

  • AllSpark 100ah LiFePO4 battery
  • AllSpark 2000W Pure Sine Wave Inverter
  • AllSpark mounting tray with 2 x 2.0m Cam buckle tie down straps
  • Redarc Core BCDCN1225 DCDC charger with 40A resetable circuit breaker
  • Victron Smart shunt battery monitor (Bluetooth)
  •  50A anderson plugs for alternator and solar inputs to BCDC
  •  2 x 50A plugs for input/output power with 60A resetable circuit breaker
  • Switch for Cig & Dual Port QC 3.0 USB A + PD65 USB Type C with 15A resetable circuit breaker protection
  • Switch for Fridge Engel/Posifit socket with 15A resetable circuit protection
  • 200A CB to connect optional extra 2000w inverter connection or use as a jump start point



AllSpark 100Ah Lithium Battery: Unleash the power of lithium with the Allspark 100Ah Lithium Battery. This high-performance battery offers a constant output of 175A and a peak output of 320A, ensuring you have the energy you need when you need it. Lightweight, compact, and with a longer lifespan than traditional batteries, the Allspark Lithium Battery is your ticket to a reliable and efficient power source.

Check out the AllSpark 100ah ABS Lithium Battery here



AllSpark 2000W Pure Sine Wave Inverter: a high quality, inverter for powering your sensitive 240V appliances, with 2000W of continuous power and a 4000W surge. It also comes with a 2500w overdrive function for shorter durations (10-30 mins subject to ambient temperatures) of additional max power.

Check out the AllSpark 2000W Pure Sine Wave Inverter here



RedArc Core BCDCN1225 DCDC: Charge your batteries efficiently and intelligently with the Redarc BCDCN1225 DC-DC Charger. This cutting-edge charger ensures a reliable power supply by optimizing the charging process, extending battery life, and adapting to various battery types. With advanced features like multi-stage charging and a maximum output of 25 amps, this charger is a powerhouse for your energy needs.

Check out the RedArc BCDCN1225 DCDC here



Victron Smart Shunt Battery Monitor: Conveiniently monitor your battery parameters, like state of charge, time to go, historical information and much more, via the VictronConnect App on your phone (or tablet).

Check out the Victron Smart Shunt here



WHATS IN THE BOX

  • 1 x AllSpark Ultimate Power Pack, including:
    • 1 x 100Ah AllSpark Lithium Battery
    • 1 x Redarc BCDCN1225 DC-DC Charger
    • 1 x Victron Smart Shunt Battery Monitor
  • 1 x AllSpark 2000W Pure Sine Wave Inverter
  • 1 x AllSpark Mounting Tray
  • 2 x AllSpark 2m Cam buckle tie down straps
  • New 2024 cell technology with compact cells and casing
  • Exclusive Solid state BMS designed and developed by Offroad Living
  • Highest quality premium grade prismatic cells - resistance matched, long battery life and no voltage sag with a 20 year design life
  • Greater than 3000 cycles @ 80% DoD before reaching 85% of original capacity
  • AllSpark 2000W Pure Sine Wave Inverter - capable of running your sensitive high powered devices
  • RedArc BCDCN1225 comes with Green Solar Priority - it will select solar charging first in an effort to reduce the load on your alternator
  • Monitor on your phone via bluetooth with the Victron 500A Smart Shunt
  •  50A anderson plugs for alternator and solar inputs to BCDC
  •  2 x 50A plugs for input/output power with 60A resetable circuit breaker
  • Switch for Cig & Dual Port QC 3.0 USB A + PD65 USB Type C with 15A resetable circuit breaker protection
  • Switch for Fridge Engel/Posifit socket with 15A resetable circuit protection
  • 200A CB to connect optional extra 2000w inverter connection or use as a jump start point

PRODUCT SPECIFICATIONS - ALLSPARK ULTIMATE POWER PACK

SKU AS-UPP100 AS-UPP100TRAY AS-UPP100INV2000
Battery

100ah AllSpark ABS Lithium

AS-10012BATLI175320G2

Battery Charger RedArc BCDCN1225 Core
Battery Monitor Victron 500A Smart Shunt
Dimensions (L x W x Hmm) Base Unit 540 x 207 x 287
Inc. Tray N/A 544 x 211 x 296
Inc. Inverter & Tray N/A N/A 544 x 211 x 406
Weight (kg) Base Unit 21.3
Inc. Tray N/A 22.3
Inc. Inverter & Tray N/A 26.9



PRODUCT SPECIFICATIONS - ABS CASE BATTERIES

SKU AS-10012BATLI175320G2 AS-15012BATLI175320 AS-20012BATLI200500G2 AS-25012BATLI200500 AS-12024BATLI175320 AS-20024BATLI200500
Battery Level Specifications
Capacity Amp Hours (C5) 100 150 200 250 120 200
Watt Hours 1,280 1,920 2,560 3,200 3,072 5,120
Rated Voltage (V) 12.8 25.625.6
Max Charge Voltage (V) 14.6 29.2
Recommended Float Voltage (V) 13.6 27.2
Low Voltage Cutoff (V) 10 20
Rapid Charge Current (1C) for 30 mins 100
Recommeded Charge Current (A)* 20-40 30-50 50-80 60-80 30-50 50-80
Charge Profile CC/CV
Max Inverter Size (Watts - per single battery)  2000 2500 4000
Max Continuous Discharge (A) 175 200 175 200
Peak Discharge - 10 secs (A) 320 500 320 500

Charge Cycles @ 80% Depth of Discharge #(with residual capacity of 85%)

@ 60% Depth of Discharge

@ 40% Depth of Discharge

> 3200+#

> 4200+

> 5000+

Optimum Temperature During Charging (˚C) < 45
Operating Temperature Range (˚C) -20 to +60
Storage Temperature Range (˚C) -40 to +125
Max Series Voltage (V) 24 48
Max Batteries in Parallel Unlimited
Dimensions (inc Handles mm)  229L x 138W x 208H 405 x 180 x 215 345 x 190 x 245 520 x 270 x 220
Case Material ABS Plastic
Weight (kg) 9.5 19 21 27 28 42
IP Rating IP65
Cell Level Specification
Cell Type Prismatic
Cell Connection 4S1P 4S2P 4S1P 4S2P 8S1P 8S1P
Cell Capacity 3.2V @ 100ah 3.2V @ 50ah 3.2V @ 200ah 3.2V @ 125ah 3.2V @ 120ah 3.2V @ 200ah
Cell Casing Nickel Plated steel
Cell Balancing target 3.65 +/- 0.025
Cell Balance Current (mA) 35 +/- 5
Cell Over Discharge LV protection (V) 2.5 +/- 0.025V
Over Discharge Release Apply Charge 10.5V+ & 1A+
Over Charge Cutoff (V) 3.75 +/- 0.025
Over Charge Detection Delay (Secs) 1-1.6
Over Charge Release (V) 3.6 +/- 0.0625V
Over Charge Release Auto below Release Voltage
Over Current Detection (1) (A) N/A 220 N/A 200
Over Curent Detection Delay (1) (Secs) N/A 10 N/A 10
Over Current Detection (2) (A) 320 500 320 500
Over Curent Detection Delay (2) (Secs) 10 5 10 5
Over Current Release Remove Load - Auto release
Short Circuit Protection External Short
Short Circuit Detection Delay (uS) 200-400
Short Circuit Recovery Remove Load - Auto release
Internal Resistance (MOSFET PROTECTION) ≤20mΩ

* For best cell longevity



Special Notes about AllSpark LiFePO4 batteries Cycle Life:

Independantly Laboratory tested with 0.2C5 Discharge rate and 0.2C Charge rate up to 5000 cycles at a controlled temperature of 25°C.  Electronic logs record during testing show a residual capacity in excess of 85% of name plate C5 capacity after 3000 cycles.  In real world conditions, the user will experience a range of temperature, current and voltage conditions which may effect the actual performance of the battery over its life.  Lower depths of discharge % and high continuous charge and discharge rates will reduce overall cycle life.  It is feasible to reach end of battery life within the warranty period should the battery be exposed to daily extremes of high current and or high temperature every cycle. Think of this type of scenerio like driving your car at 5,000rpm in first gear everywhere you drive.  It can do it, but it is not good for longevity and ultimate performance and will wear out pre-maturely.



PRODUCT SPECIFICATIONS - REDARC DCDC BATTERY CHARGERS

SKU BCDCN1225 BCDCN1240 BCDC1225D BCDC1240D BCDC1250D
Installation Location In Vehicle Only External / Under Bonnet
Battery Chemistry Standard Lead Acid, Calcium, Gel, AGM or LiFePO4
Continuous Rating (A) 25 40 25 40 50
Power Type - AC DC DC to DC
No Load Current <100mA
Solar Input Voltage 9 - 32V
Solar Switch on Voltage 9V
Standby Current <8mA
Operating Temperature -15oC to 80oC
Weight (kg) 0.9 1
Dimensions (L x W X Dmm) 165 x 120 x 37
Warranty 2 Years
Connector Type Bare wire
Input Voltage (V) 9 - 32
Output Voltage (VDC) 12
Max. Charging Voltage (V) 15.3
Max. Rated Output Current (A) 25 40 25 40 50
Nominal Output Power (W) 375 600 375 600 750
Input Fuse Rating (not supplied) (A) 40 60 40 60 60
Output Fuse Rating (not supplied) 40 60 40 60 60



PRODUCT SPECIFICATIONS - VICTRON SMART SHUNTS

SKU M.VIC-BMVSH500  M.VIC-BMVSH1000 VIC-IP65SS
Supply voltage range (VDC) 6.5 - 70
Current Draw <1mA
Input voltage range, auxillary battery (VDC) 6.5 - 70
Battery capacity (Ah) 1 - 9999
Operating Temperature Range (oC) -40 to 50
Measures coltage of second battery, or temperature, or midpoint Yes
Temperature measurement range (oC) -20 to 50
VE. Direct communication Port Yes
Resolution and Accuracy
Current (A) ±0.01
Voltage (V) ±0.01
Amp hours (Ah) ±0.01
State of charge (0-100%) (%) ±0.01
Time to go (min) ±1
Temperature (if optional temperature sensor connected) (oC) ±1 (0-50)
Accuracy of current measurement (%) ±0.4
Offset (mA) Less than 20 Less than 40 Less than 20
Accuracy of voltage measurement (%) ±0.3
Dimensions (H x W x D mm) 46 x 120 x 54 68 x 168 x 75 46 x 120 x 54
Shunt connection bolts M10
Protection category IP21 IP65
Stored Trends
Data Stored Battery voltage, current, state of charge % as well as the Aux input (Battery temperature, or midpoint deviation, or starter battery voltage)
Number of days trends data is stored 46



Specifications

SKU AS-UPP100INV2000
Brand AllSpark
Shipping Weight 26.0000kg
Shipping Width 0.400m
Shipping Height 0.335m
Shipping Length 0.650m
Shipping Cubic 0.087100000m3
